DIESEL GENERATOR 115 kVA 220 -380V, SILENT WATER COOLED

Thoughtful Design – Unmatched Features – Immense Benefits
Kirloskar generating sets have been designed giving highest consideration to end users, offering unmatched features and immense benefits to them.
From easy installation and increased reliability to faster service, lower maintenance costs and increased uptimes. Kirloskar generating sets offer distinct advantages which set new standards in engineering. That’s Kirloskar Green Power Ideas for you!

External features
– Door for radiator access Access to radiator for faster service
– Silencer mounted Inside canopy Improved safety& reduced sound level
– Mesh on exhaust tail pipe Prevents entry of pests / rodents.
– Top lifting arrangement Easy to lift by crane
– Emergency stop switch Easily accessible on canopy for stopping
– Glass window on canopy Easy to read generator parameters & safe.
– Provision of gland plate Easy cable entry & improved safety
– Stainless steel door hinges Heavy duty, anti-corrosive & long lasting
– Fuel tank full with indicator lamp Prevents fuel spillage/ wastage & improves safety
– External fuel tank filing access Ease of refueling
– Stainless steel door locks High durability & improved security
– Pockets for forklift- Facilitates easy handling & installation
– Coolant drain arrangement Easy access for faster service

Internal features
– Longer fuel tank breather tube Prevents fuel spillage due to overfilling
– High quality door rubber beading Better sound attenuation & ingress protection
– Heat insulated exhaust line Improved engine cooling efficiency & serviceability
– Coolant level sensor Supplementary engine protection
– High efficiency LED lamp Extra bright & low power consumption.
– Dual Fuel gauge (Mechanical + Electrical) Easy fuel level reading while re-fueling
– High quality PU foam Superior sound attenuation, long life, dust resistant & fire retardant
– Guard for rotating parts Enhanced safety.
– Water separator as a standard feature Prevents water entry into engine
– Lube oil drain pump Faster oil drain, reduces downtime, eliminates need of additional tray
– Control panel door stopper Facilitates service & improves safety

Frequency / 60
Voltage (L-L) / 220 – 380
Voltage (L-N) / 127 – 220
Prime Power Output (PRP) /115 KVA – 92 KW
Standby Power Output (ESP) / 126.5 KVA – 101.2 KW
Fuel Tank Capacity Open / 255
Fuel Tank Capacity Silent / 255
Fuel consumption PRP UH / 70%: 17.3 – 100%: 23.6
Sound level at 7m Silent / 70
Dimensions (LWaH) Open / 224 x 104 x 160
Dimensions (WaH) Silent / 325 x 114 x 187
Dry weight Open (Net) kg / 1450
weight Silent (Net) kg / 2120
