Digital Pressure Gauge, Calibrator Pressure Gauge, 14.7 to 15 psi, 3-inch Dial.

Ashcroft Digital Test Gauge Features:

Also known as lab test gauges, these Grade 5A digital gauges are the most highly accurate grade gauges available.
With functionality that allows users to toggle between engineering units.
These gauges are commonly used in high-precision laboratory applications where 0.05% accuracy is required.
12 engineering units
Field calibration capability
Weatherproof IP65.
Large LCD display.

Industrial Market Applications:

Test Bench / Gauge Repair Facilities
Calibration Laboratories
Mobile Calibration Labs
Test Measurement and Validation

Three accuracy levels 0.05% & 0.1% and 0.25% terminal point method
Temperature compensated from 0 to 150°F (-18-60° C)
Includes stainless steel cover and padded carry pouch
Battery powered
7 different languages

Accuracy / ±0.05%
Gauge Case Material / 304 Stainless Steel
IP/NEMA Rating / IP65
Lens Material / Polyester
Nominal
Dial Size / 3 inch
Primary Range / 14.7 to 15 psi
Wetted Parts Material / 316 Stainless Steel
Process Connection Gender / Male
Process Connection Size / 1/4 inch
Process Connection Type / NPT
Pressure Gauge Type / Test Pressure Gauge
Pressure Range Type / Pressure
Primary Units / psi
Includes Calibration Certificate / 10 NIST Traceable Chart
Includes / Padded Carry Pouch; Stainless Steel Cover
Manufacturer Part Number / 2089
Series / 2089
Adjustable Set Points / Yes
Application / Laboratory; Test and Measurement
Auto-Shutoff / Yes
Auto-Shutoff Time / 2 min; 5 min; 15 min; 30 min
Backlit Screen / Yes
Bar Graph / 10 Segments
Battery Run Time / 1,000 hr
Battery Type / (3) AAA Batteries
Blowout Safety Back / No
Burst Pressure / 45 psi
Case Color / Silver
Case Depth / 1.7 inch
Case Diameter / 3.25 inch
Case Finish / Tumble Polished
Case Shape / Round
Data Update Frequency / 100 msec; 200 msec; 500 msec; 1 sec
Digit Height / 0.66 inch
Display Range / 14.7 to 15 psi
Display Screen Type / LCD
Display Units / Bar; cm H2O; ft SW; in H2O; in Hg; kg/sq cm; kPa; mBar; mm H2O; mm Hg; Mpa; psi
Hazardous Location Rating / Not Rated
Includes Batteries / Yes
Includes Mounting Hardware / No
Includes Rubber Boot / No
Languages / Dutch; English; French; German; Italian; Portuguese; Spanish
Low Battery Indicator / Yes
Manufacturer Warranty Length / 1 yr
Memory Features / Min/Max
Mounting Type / Stem-Mount
Non-Sparking / No
Number of Digits / 5
Panel-Mountable / No
Peak Hold / No
Power Source / Battery
Process Temperature Range / 0° to 150°F
Sensor Material / 316 Stainless Steel
Sensor Type / Silicone MEMS
Socket Material / 316 Stainless Steel
Standards / CSA; FM Approved
Case Material / Stainless Steel
Connection Location / Bottom
Gauge Wetted Parts / Stainless Steel
Pressure Range / 14.7 to 15 psi psi
Process Connection / 1/4 inch NPT Male
Process Connection Location / Bottom
Test Pressure Gauge Type / Calibrator Pressure Gauge
With Calibration Certificate / With Calibration Certificate
Weatherproof / Yes
