hydraulic hand pump, 25 ton

Features

Solid bronze glands and wear ring for long life.
Male NPT threads on the rod end and female NPT in base.
Chrome-plated piston rods resist corrosion and wear.
Quick-connect coupling for fast setup.

Cylinder Cap. (Tons) / 25
Stroke (In) “D” / 6 1/4
Model Number / RC-25-SA-6
Closed Height “C” / 10 3/4
Ext. Height (In) / 17
Eff. Area (Square Inch) / 4.90
Oil Capacity (Cubic Inch) / 30.6
Outside Diameter “A” / 3 3/8
Rod Diameter “B” / 2 1/4
Bottom to Port Diameter “E” / 1
Plunger Thread / 1 1/2-16 x 9/16
Collar Thread “F” / 3 5/16-12 x 2
Mounting Holes “G” / (2) 1/2-13, 2 5/16 Dia.B.C. HP-50
Oil Capacity (Cubic Inch) / 37
Type of Cylinder / Single Acting
Handle Length (In) / 22
Length (in) / 19 3/4
Width (in) / 5
Height (in) / 5 1/2
Weight (lb) / 16
Rated Pressure 1st Stage (psi) / N/A
Rated Pressure 2nd Stage (psi) / 10,000
Oil Displacement per Stroke 1st Stage (Cubic Inch) / N/A
Oil Displacement per Stroke 2n Stage (Cubic Inch) / .19
