بوش – شاحن بطارية لشحن بطاريات الرصاص الحمضية 24 فولت

Product Features

• 12 A battery charger
• 6 x individually fused 40A outputs
• 3 x 5A auxiliary outputs
• 150 A back‑up current
• Fully supervised, EN 54‑4 certified
• Under‑voltage / over‑voltage / incorrect battery polarity / short circuit protection

Specifications

Mains Power Supply

• Voltage: 195 to 264 VAC, 50 to 60Hz
• Input current: 2 A
• Power consumption: 380 W maximum

Performance

• Voltage min.: 21.6 VDC (auto shutdown)
• Voltage max.: 28.5 VDC
• Max. charge current: 12 A
• Max. system current (Ib): 150 A

Main Outputs (6x)

• Voltage: 24 VDC (battery voltage)
• Current: 40 A

Auxiliary Outputs (3x)

• Voltage: 24 VDC (battery voltage)
• Current: 5 A

Fault Outputs (3x)

• Rating: 24 V / 1 A, 120 VAC / 500 mA voltage free
• Contacts: Normally energized (failsafe)

Mechanical

• Dimensions (H x W x D): 88 x 483 x 340 mm (19″ wide, 2U high)
• Input connections (connect to battery): Screw terminal
• Output connections (connect to system): 10 x pluggable screw connector
• Weight: Approx. 6 kg
• Mounting: 19” rack
• Colour: Charcoal with silver
